How to Install an Under-Sink Water Filter

Disclosure: Water Filter To Go is reader-supported. When you buy through links on this site we may earn a small affiliate commission at no extra cost to you.

Quick Overview: Installing an under-sink water filter is a manageable DIY project that most homeowners and many renters can complete in 30–90 minutes with basic tools. This guide covers both standard under-sink carbon filters and under-sink reverse osmosis (RO) systems, step by step. No plumber required for most installs. For help choosing the right system before installing, see our Best Water Filters guide.

What You’ll Need

• The filter system and all included fittings (most kits include everything)
• Adjustable wrench or channel-lock pliers (two recommended)
• PTFE (plumber’s) tape
• Tubing cutter or sharp scissors (for push-fit tubing)
• Drill with 7/8-inch or 1/2-inch bit (for RO faucet install only)
• Bucket or towels
• Flashlight or work light
• Marker and measuring tape

Step 1 — Choose Your Installation Location

Open the cabinet under your kitchen sink and assess the space. You need room to mount the filter housing (typically a single canister for carbon systems, or a multi-canister unit for RO) and route tubing without kinking. Things to check:

• Identify the cold water supply line — it typically runs from the floor or wall to the cold water shutoff valve under the sink.
• Confirm there is a flat surface to mount the filter bracket (most systems include a wall-mount bracket or a floor-standing base).
• For RO systems: assess space for the storage tank (typically 10–14 inches in diameter, 14–18 inches tall) and the drain saddle connection on the drain pipe.
• For RO systems: check if your sink or countertop already has an unused hole (often covered by a decorative cap) for the filtered water faucet — if not, you’ll need to drill one.

Step 2 — Shut Off the Cold Water Supply

1. Locate the cold water shutoff valve under the sink — it is on the cold (right) side of the supply lines, typically a small oval or round handle. Turn it clockwise until fully closed.
2. Open the cold water faucet at the sink to release pressure and drain any water remaining in the line.
3. Place a towel or small bucket under the supply line connection before disconnecting anything.

Step 3 — Install the Feed Water Adapter (Tee Fitting)

This is how filtered water is tapped off the cold supply line:

1. Standard under-sink carbon filter: Disconnect the cold supply line from the shutoff valve. Thread the included tee adapter onto the shutoff valve outlet. Wrap the threads with two layers of PTFE tape first. Reconnect the original supply line to one port of the tee. The second port of the tee feeds the filter input.
2. Alternative — needle saddle valve (push-in): Some kits include a saddle valve that clamps onto the supply line and uses a self-piercing needle. These are convenient but can be prone to leaks over time; the tee fitting method above is more reliable.
3. Run the included tubing from the tee adapter to the filter inlet port. Cut tubing to length with a clean straight cut — angled cuts cause push-fit connections to leak. Push tubing fully into the fitting until it stops (you should feel it click or bottom out).

Step 4 — Mount the Filter Housing

1. Hold the filter bracket or housing against the cabinet wall at the chosen location. Mark the screw holes with a pencil.
2. Drill pilot holes if mounting to particleboard (common in kitchen cabinets) — this prevents splitting.
3. Screw the bracket in place. Hang or clip the filter housing onto the bracket.
4. Connect the inlet tubing (from the supply tee) to the filter’s IN port. Connect a second length of tubing from the filter’s OUT port toward the faucet (for carbon systems) or toward the RO unit inlet (for RO systems).
5. Ensure all tubing is routed without sharp bends or kinks — these restrict flow and stress the tubing walls.

Step 5 (RO Only) — Install the Faucet

1. If your sink has an unused hole: remove the decorative cap, insert the RO faucet stem through the hole from below, and secure with the included washer and nut from underneath.
2. If no spare hole exists: use the drill and 7/8-inch or 1/2-inch hole saw bit (depending on faucet stem diameter) to drill a new hole in the stainless steel sink or countertop. Drill through a thin area away from existing pipes and disposal hardware. Use cutting oil to keep the bit from overheating on stainless.
3. Mount the faucet. Connect the thin tubing from the RO output to the faucet’s inlet stem.

Step 6 (RO Only) — Install the Drain Saddle

RO systems produce wastewater that must drain. The drain saddle taps into the sink’s drain pipe:

1. Choose a point on the drain pipe that is above the P-trap (curved section). Mark the drill location on the side or top of the drain pipe.
2. Drill through the drain pipe at the marked point using the included drill bit.
3. Clamp the drain saddle over the hole with the included screws. The saddle port should align with the hole.
4. Connect the drain tubing from the RO unit to the saddle port. Route the tubing so it runs downhill to the drain — no uphill loops, which can cause back-siphoning.
5. Connect the storage tank tubing per the manufacturer’s diagram — typically: supply tee → RO pre-filter → RO membrane → post-filter → storage tank, then tank → faucet.

Step 7 — Flush the System Before Use

1. Slowly turn the cold water shutoff valve back on. Check every connection immediately for drips — tighten any fittings that show moisture.
2. Carbon systems: Let filtered water run for 3–5 minutes to flush out carbon fines (dark gray water is normal and harmless). Discard this water.
3. RO systems: Let the storage tank fill fully (typically takes 2–4 hours). Then open the RO faucet and drain the tank completely — discard this first tank. Repeat with a second fill and discard. This flushes manufacturing residues and saturates the membrane. Water from the third fill is ready to drink.

Step 8 — Check for Leaks

With water back on and the system running, inspect every connection point under the sink. Press a dry paper towel against each fitting and check for moisture. Check again after 30 minutes. Common leak points to inspect:

• Tee fitting at the shutoff valve
• All push-fit tubing connections at the filter ports
• Drain saddle clamp (RO only)
• Faucet base nut (RO only)
• Storage tank connection (RO only)

Most push-fit leaks are fixed by ensuring the tubing is pushed all the way in — disconnect, cut 1/4 inch off the end of the tubing to get a fresh clean face, and re-insert firmly. Threaded leaks are fixed by adding more PTFE tape and retightening.

Troubleshooting Common Issues

Maintenance Reminder

Installation is one-time; filter changes are recurring. Mark the install date on the filter housing with a permanent marker. Most under-sink carbon systems need filter replacement every 6 months. RO systems have staged replacement schedules: pre/post-filters every 6–12 months, the RO membrane every 2–5 years. For a full replacement schedule by filter type, see How Often Should You Change a Water Filter?

[Check Price on Amazon]

Frequently Asked Questions

Do I need to hire a plumber to install an under-sink water filter?

For most standard under-sink carbon filters, no — the installation involves push-fit tubing connections and a tee adapter, with no soldering or pipe cutting. RO systems are more complex (drain saddle, faucet drilling) but most confident DIYers complete them successfully in 60–90 minutes. If your supply lines use compression fittings with unusual sizes, or if the cabinet has very limited access, a plumber can complete the job in under an hour for roughly $100–$200.

Will installing an under-sink filter affect my main tap water pressure?

No — under-sink systems draw from the cold supply line but deliver filtered water through a separate dedicated faucet. The main kitchen faucet continues to operate at full pressure. The only exception is some in-line diverter models that route all cold water through the filter — these can slightly reduce peak flow rate.

Can I install an under-sink filter in a rented apartment?

Standard under-sink filters require only a tee adapter on the supply line — no permanent plumbing modification. Most landlords permit this; check your lease. RO systems requiring a dedicated faucet hole are more likely to need approval. If neither is feasible, a countertop RO or pitcher filter requires zero installation and moves with you.

What water pressure do I need for a reverse osmosis system?

Most RO systems require a minimum of 40 PSI and function optimally at 60–80 PSI. Below 40 PSI, the membrane efficiency drops significantly and the tank fills very slowly. If your home has low water pressure, a small booster pump (typically $40–$80) can be added to the RO inlet line. Standard municipal water pressure in the US is typically 40–80 PSI.

For our vetted under-sink filter recommendations, see the Best Water Filters guide.
